Description
Default the Nordic UART UUIDs are used for service and characteristic. You can change them with the option menu Configuration.
The first optional information is a channel, which has the range from 0 to 3.
Afterwards 2 positions are handled as bytes and are terminated with a zero byte.
The range of the positions (power) is between -100 and 100.
Mode standard enabled:
UP: [channel,] 0, power, 0
DOWN: [channel,] 0, -power, 0
LEFT: [channel,] -power, 0, 0
RIGHT: [channel,] power, 0, 0
MIDDLE: [channel,] 0, 0, 0
Mode standard disabled:
UP: [channel,] 0, power, 0
DOWN: [channel,] 0, -power, 0
LEFT: [channel,] -power, power, 0
RIGHT: [channel,] power, power, 0
MIDDLE: [channel,] 0, 0, 0
Byte Mode enabled: Optional channel and 3 positions are transfered as bytes
Byte Mode disabled: Optional channel (seperated by colon) and 3 positions are transfered as text seperated by colon (ended by \n)
Zero: On Release automatic return to zero values. [channel], 0, 0, 0
Channel (Ch.): Enable optional channel information (first byte or text seperated by colon)
Power: Slider from 0 to 100
