DEVELOPED SECTION for AutoCAD or BricsCAD
So, you're looking for a handy software solution that can handle those unfolded sections of entities like 3DSOLID, 3DMESH, or 3DFACE? Well, checking out DEVELOPED SECTION for AutoCAD or BricsCAD might just be what you need!
What is Developed Section?
This tool is a cool add-on compatible with both AUTOCAD 2002-2018 and BricsCAD v16-17. It doesn’t just help you figure out the values of those entities; it can also handle vertical plans that cut through a 2D POLYLINE.
Working with 2D Polylines
You’ll be glad to know that this 2D POLYLINE can even include arcs in an XOY plane! When the vertical plane intersects with the first segment of your POLYLINE, you get a developed section presented as 3DPOLY entities.
User-Friendly Features
If you ever need to check the gauge underneath a passage without unfolding anything, this software has got your back! You can easily create two viewports for printing based on your specified dimensions. One viewport shows the initial view, while the other presents the unwrapped plan section.
Precision Matters!
An exciting feature is that users can set how precise they want the concatenation of segments at the intersection to be. This option allows for more control when using DEVELOPED SECTION for AutoCAD or BricsCAD.
Your Next Step!
If you think this sounds like something you could use, don’t hesitate to give it a try! It’s user-friendly and packed with features that make handling unfolded sections much simpler.
