PPMScope
PPMScope is a cool DIY oscilloscope that anyone can build, thanks to its Open Source design. If you're into electronics, this could be a fun project for you!
Easy to Build
The great thing about PPMScope is that it’s made for electronics enthusiasts. You get clear instructions that guide you through the whole process. So whether you're a beginner or have some experience, you'll find it doable.
Features and Cost
This oscilloscope strikes a balance between features and price. While it doesn’t have all the bells and whistles of commercial scopes, it's still pretty handy for basic tasks. Just keep in mind that its bandwidth is limited to signals of 500 kHz and below.
Sufficient Sampling Buffer
Now, about the sample buffer—it's smaller than what you'd find in commercial oscilloscopes but still good enough for most functions. This means you can effectively monitor signals without any hassle.
Microcontroller Details
This version runs on the PIC16F877A microcontroller at a 20MHz clock speed. It achieves a maximum sampling rate of 1 MHz with an equivalent of 5 MHz sampling. So while it may not be top-tier, it gets the job done quite well!
Download PPMScope Now!
If you’re ready to dive in and start building your own oscilloscope, check out this link. It’ll take you straight to where you can download everything you need!
